A-16657
Motor Opto Switch PCB Assembly
(for mini playfield)
J1
0.0000
J1
ROW 1
J1-1 White-Yellow, switch row 4, from CPU Board J209-4
J1-2 White-Green, switch row 5, from CPU Board J209-5
J1-3 Black, ground, from Power Driver Board J118-3
J1-4 Gray-Yellow, +12V, from Power Driver Board J118-2
J1-5 Key
J1-6 Violet-White, switch column 9, from 8-Driver Board J5-4
R1
470.0
R2
470.0
+12VDC 4
ROW2
2
KEY 5
J2
Mlnl-plsyfield
Molor
Driver Board
OplO Switch Board
INDIANA JONES 3-24
