Show Date and Time
The operator chooses whether the date and time show in the Attract Mode. The
choices are:
Yes
No
Show the date. time in status report or in the Attract Mode.
Do Not show date, time in status report or in the Attract Mode.
25
Allow Dim Illumination
The operator chooses whether to allow the game program to dim the General
Illumination for special effects and during the Attract Mode. The choices are:
Yes
No
Dim the General Illumination during the Attract Mode.
Do Not dim the General Illumination.
Tournament Play
The operator chooses whether to equalize Multi-ball and Jackpots during
multi-player games, (do not carry over to next player). The choices are:
Yes
No
Keep Multi-ball and Jackpots equal.
Do Not Keep Multi-ball and Jackpots equal.
Z7
Euro. Scr. Format
The operator chooses whether to have commas or dots between digits when
numbers are displayed. The choices are:
Yes
No
Dots instead of commas, (example-
1.000.000).
Commas instead of dots, (example-
1. 000, 000).
Minimum Volume Control
The operator chooses whether the volume can be turned Off. The choices are:
Yes
No
Volume can be turned Off.
Volume can be turned Down but not Off.
G.I. Power Saver
Thls
adjustment allows the General Illumination and Controlled lamps to be
dimmed following a time interval after a game is played. Al 30 (Power Saver
Level) determines how dim the lamps get. Using this feature substantially
increases the life of the lamps. The range of this setting is Off. 2 through 60
minutes.
Power saver Level
When Al 29 (G.I. Power Saver) Is set to On. this adjustment controls the
intensity of the G.I. and Controlled lamps once the game has been idle for a
specified time period. The range of this setting is
4
through
7.
Ticket Expansion Board
When a Ticket Expansion Board is connected, full control of the ticket dispenser
is available. This includes a ticket low/error lamp, resume on ticket jam switch
and manual ticket dispense switch. The choices are:
Yes
No
Ticket Expansion Board is connected.
Ticket Expansion Board is NOT installed in the game.
Press the Escape button to return to the Adjustments Menu. Press the Up button to advance to
the next desired Adjustments Group, (or press the Down button to return to a previous group).
Press the Enter button to activate. Use the Up or Down button to cycle through the available
adjustments.
Hurricane 1-28
