5. Raise the hinged backbox upright and latch it into position.
Unlock the backbox, and
remove the backglass, storing it carefully to avoid scratches.
Remove the shipping block
holding the Insert Board. Unlatch and open the Insert Board. Carefully lift up the Speaker
Panel and lay It down on the playfteld glass. (Be careful not to damage the Dot Matrix
Display /Dnver.) This allows access to the bolt holes used for securing the backbox upright. To
secure the backbox, install the washer-head mounting bolts through the bottom holes of the
backbox into the threaded fasteners in the cabinet. Close the Insert Board and latch it in
position. Replace the Speaker Panel. Reinstall the backglass. and lock the backbox.
A
CAUTION
FAILURE
TO
INSTALL
the backbox mounting hardware properly can cause personal injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erect. Always lower the backbox
forward onto the playfield cabinet on a layer of protective material to prevent marring or
damage and possible personal injury.
6. Extend each leg leveler
slightly
below the leg bottom, so that all four foot pads are extended
about the same distance. Remove the cabinet from its support and place it on the floor.
7. Unlock and open the coin door. Locate the Molding Latch Lever. and move the lever toward
the left side of the game. to release the Front Molding. Lift the Front Molding off the playfteld
cover glass return the Latch Lever toward the right. and close the coin door. Carefully slide the
glass downward. until It clears the grooves of the Left and Right Side Moldings. Lift the glass up
and away from the game. storing it carefully to avoid breakage.
S. Place a level or an inclinometer on the playfield surface. Adjust the leg levelers for proper
playfield level (side-to-sidel and playfleld pitch angle (incline) of approximately 6-7 degrees.
Note:
It is recommended that these measurements be made ON the playfleld, not the cabinet
nor the playfield cover glass. TIghten the nut on each leg leveler shaft to maintain this setting.
as shown in Figure 1.
!
IMPORTANT!
Playfield pitch angle adjustments can affect the operation of the plumb bob tnt. inside the
cabinet. The plumb bob weight Is among the parts In the cash box; the operator should install
the weight and adjust this tnt mechanism for proper operation. after completion of the desired
playfield pitch angle setting.
9. Move the game into the desired location; recheck the level and pitch angle of the playfield.
10. Verify that the required number of balls are installed in the game. Hurricane uses 3 balls.
11. Install playfield mylars if desired.
Note:
The
Hurricane
playfield is coated with a covering called Diamond Plate™ and does not
require a protective mylar. However. mylars can be purchased through your local Williams
Distributor. Specify part number 03-7960-50012-1 for full playfleld mylar.
12. Clean and reinstall the playfleld cover glass. reversing the procedure of step 7. Prepare the
game for player operation.
Hurricane 1-3
