Pinball Game Assembly Instructions
A
CAUTION
After assembly and installation at its site location, this game must be plugged into a properly
grounded outlet to prevent shock hazard, and to assure prpoer operation. DO NOTuse a
'cheater' plug to defeat the groundpin on the line cord. DONOTcut off the ground pin.
Hurricane is a three baDgame.
1. Remove all cartons, parts, and other items from the shipping container, and set them aside.
2. Place the cabinet on a support and attach rear legs using leg bolts. Leg levelers and leg bolts
are provided among the parts in the cash box.
3. Attach the front legs (after installing leg levelers), using leg bolts. See Figure 1 for details.
I
I
I
I
I
I
I
I
I
-,
I
I
I
...•.\
I
...•....•.\
I ...•....•. \
I ...•.
\
"
",'
....
'"
",
" I
...•."
", I
",
",rr---":''''------I
I \
I
I
",,'"
I
I....
\ 1/
",
I
--~.....
I
j.,,---~.:!I' ---
.
Approx Playfield
Pitch Angle:
6-7Degrees
Nut
4422-01117-00
,
See Detail View ~
Detail View -
Leg Leveler
C-10843
Leg
~~It-08-7377Leg
Leveler
Figure 1. Plnball.Assembly, Playfleld Pitch Angle, and Leg Leveler Details.
4. Reach into the cabinet and backbox and ensure that the interconnecting cables are free to
move (not kinked or pinched). Be careful to avoid damaging wires at any stage of the assembly
process.
Hurricane 1-2
