8-12665 Kicker Arm (Slingshot) Assembly
<,
-,
<,
..... .....
<,
<,
.....
...••
-,
.....
•....
.....
•....
.....
•....
.....
•....
•....
.
.....
...••
...••
...••
...••
.....
...••
•....
.....
•....
•....
•....
.....
.....
..... .....
Associated Parts for Right & Left Kickers
Item Part Number
Description
Item Part Number
Description
1.
12-6227
Hairpin Clip
6.
8-11203-R-1
Coil & Bracket Assembly
2.
A-12664
Kicker Crank Assembly
a) B-7572-1
Bracket & Stop Assembly
3.
A-5653
Mounting Bracket Assembly
b) 01-8-508-S
Coil Retaining Bracket
4.
4700-00030-00 Flatwasher, 17/64 x 1/2 x 15ga.
c) 4006-01017-06
Mach. Screw, 6-32 x 3/8
5.
A-51 03
Coil Plunger Assembly
d) 4406-01119-00
Nut, 6-32 ESN
a) 02-2364
Coil Plunger
e) AE-26-1500
Coil Assembly
b) 03-8085
Armature Link
f)
03-7066
Coil Tubing
c) 20-8716-5
Roll Pin, 1/8 x 7/16"
7.
10-128
Spring
DOCTOR WHO 2-22
