DOT MATRIX CONTROLLER BOARD
A-14039
C\I
'<t
J603
c:=;:j"
~
J601
2
10
20
30
J602
1~ 2
10
20
J606
]
,---=J6=0=4'ri
___.I I
1
605
I
8
1 5
1
J601 Ribbon Cable, Data to/from J202; J903; J506
J604-1 Orange, -125V to Dot Matrix Display Driver Pin 1
J604-2 Blue, -113V to Dot Matrix Display Driver Pin 2
J604-3 Key
J604-4 Black, Ground to Dot Matrix Display Driver Pin 4
J604-5 Black, Ground to Dot Matrix Display Driver Pin 5
J604-6 Gray, +5V to Dot Matrix Display Driver Pin 6
J604-7 Gray-Yellow, +12V to Dot Matrix Display Driver Pin 7
J604-8 Brown, +62 to Dot Matrix Display Driver Pin 8
J5xx Audio Board
J6xx Dot MatrixControllerBoard
J9xx FllptronIe II Board
J602 Ribbon Cable, Data from J201
poCo
Board Lagend
J1-J6 Coin Door InterfaceBoard
J1xx Power DriverBoard
J2xx CPU Board
J603 Ribbon Cable ,Data to Dot Matrix Display Driver
J605-1 White, 80VAC from transformer secondary
J605-2 White, 80VAC from transformer secondary
J605-3 Violet, 1OOVAC from transformer secondary
J605-4 Key
J605-5 Violet, 100VAC from transformer secondary
J606-1 Black, Ground loop from J606-3
J606-2 Key
J606-3 Black, Ground from J117-3
J606-4 Gray, +5V loop from J606-5
J606-5 Gray, +5V from J117-4
J606-6 Gray-Yellow, +12V loop from J606-7
J606-7 Gray-Yellow, +12V from J 117-2
DOCTORWHO 3-25
