FLiPTRONIC II BOARD
A-15472
110000000 0 0
*
00 0113
J902
~
J904
~~I
J~9_03~__
~I~~
1
0
°*°°1
5
1
J901-1 White-Blue, 50VAC loop from J105-1
J901-2 White-Blue, loop from J901-1
J901-3 White-Blue, 50VAC loop, from J105-2
J901-4 Key
J901-5 White-Blue, loop from J901-3
J902-1 Orange-Gray,?
J902-2 Not Used
J902-3 Black-Blue,?
J902-4 Not Used
J902-5 Not Used
J902-6 Not Used
J902-7 Orange-Blue, holding to lower left flipper
J902-8 Not Used
J902-9 Blue-Gray, power to lower left flipper
J902-10 Key
J902-11 Orange-Green, holding to lower right flipper
J902-12 Not Used
J902-13 Blue-Violet, power to lower right flipper
J903 Ribbon Cable, data to/from J202; J506; J601
J904-1 Gray, +5V from J114-4
J904-2 Gray-Green, +12V from J114-2
J904-3 Key
J904-4 Black, Ground from J114-7
J904-5 Black, Ground from J 114-5
-~
0
°
~
*
0
°
...,
°°
~CJ)
§m: ~
...,*
°
LO
J906
jl_
1°
0
°°*°1
u
6
1
J905-1 Blue-Violet, to right flipper opto
J905-2 Blue-Gray, to left flipper opto
J905-3 Black-Yellow, to right flipper opto
J905-4 Key
J905-5 Black-Blue, to left flipper opto
J905-6 Orange, Switch Ground
J906-1 Black-Green, to lower right end-of-stroke switch
J906-2 Key
J906-3 Black-Blue, to lower left end-of-stroke switch
J906-4 Not Used
J906-5 Black-Gray, to upper left end-of-stroke switch
J906-6 Orange, Switch Ground
J907-1 Blue-Yellow, +50V to lower right flipper
J907-2 Blue-Yellow, loop from J907-1
J907-3 Key
J907-4 Gray-Yellow, +50V to lower left flipper
J907-5 Gray-Yellow, loop from J907-4
J907-6 Not Used
J907-7 Not Used
J907-8 Gray-Yellow, loop from J907-9
J907-9 Gray-Yellow, +50V to upper left flipper
p,c,
Board Legend
J1-J6 CoinDoor InterfaceBoard
Jtxx PowerDriverBoard
J2xx CPUBoard
J5xx AudioBoard
J6xx Dot MatrixControllerBoard
J9xx FllptronlcII Board
DOCTORWHO 3-26
