AUDIO BOARD
A-12738-20006
JS06
1~2 10
20
30
I JS01
7
I JSOSII JS04 I
4 14 1
J501-1 Gray-Green, 20VAC from transformer secondary
J501-2 Gray-Green,
loop from J501-1
J501-3 Key
J501-4 Gray, 20VAC from transformer secondary
J501-5 Gray, 20VAC loop from J501-4
J501-6 Gray-White, 20VAC loop from transformer secondary
J501-7 Gray-White, 20VAC loop from J501-6
J502-1 Gray, +5VDC from J114-4
J502-2 Key
J502-3 Gray, +5VDC from J114-3
J502-4 Black, Ground from J114-7
J502-5 Black, Ground from J114-5
J503 Not Used
J504-1 Not Used
J504-2 Not Used
J504-3 Black, Signal to speaker
J504-4 Not Used
DOCTORWHO 3-24
J505-1 Not Used
J505-2 Black-Yellow, Signal to speaker
J505-3 Not Used
J505-4 Not Used
J506 Ribbon Cable, Data tolfrom J601 ; J903; J202
J507 Not Used
J508 Not Used
J509 Not Used
p.C.
Board Legend
J1·J6 CoinDoor InterfaceBoard
J1xx PowerDriverBoard
J2xx CPUBoard
J5xx AudioBoard
J6xx Dot MatrixControllerBoard
J9xx FllptronlcII Board
