CPU BOARD
A-12742-20006
J201 Ribbon Cable, Data to J602
J202 Ribbon Cable, Data to J903; JS06; J601
J203 Not Used
J204 Not Used
J20S-1 Orange-Brown, Dir Sw 1, Left Coin to J1-14
J20S-2 Orange-Red, Dir Sw 2, Center Coin to J1-13
J20S-3 Orange-Black, Dir Sw 3, Right Coin to J1-12
J20S-4 Orange-Yellow, Dir Sw 4, 4th Coin J1-17
J20S-S Key
J20S-6 Orange-Green, Dir Sw S, Escape/Service to J1-11
J20S-7 Orange-Blue, Dir Sw 6, DownNolume Down to J1-10
J20S-8 Orange-Violet, Dir Sw 7, UpNolume Up to J1-9
J20S-9 Orange-Gray, Dir Sw 8, EnterlT est to J 1-S
J20S-10 Black, Ground to J 1-1S
J20S-11 Not Used
J20S-12 Orange-White, Enable to J1-1S
J206-1 Green-Brown, Sw Col 1 to Playfield Switches
J206-2 Green-Red, Sw Col 2 to Playfield Switches
J206-3 Green-Orange, Sw Col 3 to Playfield Switches
J206-4 Green-Yellow, Sw Col 4 to Playfield Switches
J206-S Green-Black, Sw Col S to Playfield Switches
J206-6 Green-Blue, Sw Col 6 to Playfield Switches
J206-7 Green-Violet, Sw Col 7 to Playfield Switches
J206-S Key
J206-9 Green-Gray, Sw Col S to Playfield Switches
J207 Not Used
J208-1 White-Brown, Sw Row 1 to Playfield Switches
J208-2 White-Red, Sw Row 2 to Playfield Switches
J208-3 White-Orange, Sw Row 3 to Playfield Switches
J208-4 White-Yellow, Sw Row 4 to Playfield Switches
J208-S White-Green, Sw Row S to Playfield Switches
J208-6 Key
J208-7 White-Blue, Sw Row 6 to Playfield Switches
J20S-8 White-Violet, Sw Row 7 to Playfield Switches
J208-9 White-Gray, Sw Row 8 to Playfield Switches
J209 Not Used
J210-1 Black, Ground from J114-7
J210-2 Key
J210-3 Black, Ground from J114-S
J210-4 Gray, +SVDC from J114-4
J210-S Gray, +SVDC from J114-3
J210-6 Gray-Green, +12VDC from J114-2
J210-7 Gray-Green, +12VDC from J114-1
o
"'[]].
~
~.
(0)
o
"''''
"'lJ1
J212 J206 J208
1000.00001
lotlooooooolloo.oooool
B
J205
1 9
J207
1 9
J209
1
Go.oooooooo4
1_00000001 100.000001
12
19
1 9
1
J211 Ribbon Cable, Data from J113
o
o
J212-1 Green-Brown, Sw Col 1 to J1-1
J212-2 Green-Red, Sw Col 2 to J1-7
J212-3 Green-Orange, Sw Col 3 to J2-3 on
S-Sw.
&
Diode P.C.
J212-4 White-Brown, Sw Row 1 to J1-6
J212-S Key
J212-6 White-Red, Sw Row 2 to J1-S
J212-7 White-Orange, Sw Row 3 to J1-4
J212-8 White-Yellow, Sw Row 4 to J1-3
p.c.
Board Legend
J1-J6 CoinDoor InterfaceBoard
J1xx PowerDriverBoard
J2xx CPUBoard
J5xx AudioBoard
J6xx Dot MatrixControllerBoard
J9xx FliptronicII Board
DOCTORWHO 3-23
