POWER DRIVER BOARD
A-12697-1
J101-1 Red, 9VAC from transformer secondary
J1 01-2 Red, 9VAC from transformer secondary
J101-3 Key
J101-4 Blue-White, 13VAC from transformer secondary
J1 01-S Blue-White, loop from J1 01-4
J101-6 Blue-White, 13VAC from transformer secondary
J101-7 Blue-White, loop from J101-6
J102-1 White-Red, loop from J1 02-2
J102-2 White-Red, 16VAC from transformer secondary
J1 02-3 White-Red, loop from J1 02-4
J1 02-4 White-Red, 16VAC from transformer secondary
J102-S Black-Yellow, loop from J1 02-6
J 102-6 Black-Yellow, 16V AC from transformer secondary
J102-7 Key
J102-8 Black-Yellow, loop from J1 02-9
J1 02-9 Black-Yellow, 16VAC from transformer secondary
J103 Not Used
J104-1 White-Blue, SOVAC to J901-1
J104-2 White-Blue, SOVAC to J901-3
J104-3 Key
J104-4 Not Used
J104-S Not Used
J10S Not Used
J 106-1 Not Used
J106-2 Not Used
J106-3 Not Used
J106-4 Key
J106-S Red, +20V to insert flash lamps
J107-1 Not Used
J107-2 Violet-Orange, SOV to coils
J107-3 Violet-Yellow, SOV to coils
J107-4 Key
J107-S Red, +20V to flashlamps
J107-6 Red-White, +20V to flashlamps
J108 Not Used
J109 Not Used
J110 Not Used
J111 Not Used
laa.af
laaalllaa.aal
IDa.aaaal
1 4 1
9
1
7
J103 J102
J101
'"
'"
m~ rn" ~
-
.
-
""')
:
"")
_
_
rn '"
r-,o
_.::;
ill '"-
-
_,
J113
J114
J115
~
laaa.DaoaaaDai
7
c:::.:::.::J
1 12
1
: 1:::::::::::::::::1;
J112-1 White-Green, 9.8VAC from transformer secondary
J112-2 White-Green, loop from J112-1
J112-3 White-Green, 9.8VAC from transformer secondary
J112-4 Key
J112-S White-Green, loop from J112-3
J113 Ribbon Cable, Data tolfrom J211
J114-1 Gray/Green, +12VDC to J21 0-7
J114-2 Gray/Green, +12VDC to J21 0-6; J904-2
J114-3 Gray, +SVDC to J21 O-S; JS02-3
J114-4 Gray, +SVDC to J21 0-4; JS02-1; J904-1
J114-S Black, Ground to J210-3; JS02-S; J904-S
J114-6 Key
J114-7 Black, Ground to J21 0-1 ; 'JS02-4; J904-4
P,C,
Board Lagend
J1-J6 CoinDoor InterfaceBoard
J1xx PowerDriverBoard
J2xx CPUBoard
J5xx AudioBoard
J6xx DotMat'rlxControllerBoard
J9xx FliptronicII Board
DOCTORWHO 3-20
