COIN DOOR INTERFACE BOARD
A-14689
11 000000005booooo.00
11S 100.OJ&000IS
c:o
o
o
o
co.
-'0
o
o
o
J1-1 Green-Brown, switch column 1 fromJ212-1
J1-2 Red-Gray, lamp row S from J134-9
J1-3 White-Yellow, switch row 4 from J212-S
J1-4 White-Orange, switch row 3 from J212-7
J1-5 White-Red, switch row 2 from J212-6
J1-6 White-Brown, switch row 1 from J212-4
J1-7 Green-Red, switch column 2 from J212-2
J1-S Orange-Gray, dedicated switch row S from J205-9
J1-9 Orange-Violet, dedicated switch row 7 from J205-S
J1-10 Orange- Blue, dedicated switch row 6 from J205-7
J 1-11 Orange-Green, dedicated switch row 5 from J205-6
J 1-12 Orange-Black, dedicated switch row 3 from J205-3
J1-13 Orange-Red, dedicated switch row 2 from J205-2
J1-14 Orange-Brown, dedicated switch row 1 from J205-1
J1-15 Black, Ground from J205-1 0
J1-16 Key
J1-17 Orange-Yellow, dedicated switch row 4 from J205-4
J1-1S Orange-White, switch enable from J205-12
J2-1 Violet, G.I. return from J119-3
J2-2 White-Violet, G.I. 6.SVAC from J119-1
J2-3 Key
J2-4 Gray-Yellow,
+
12V from J116-2
J2-5 Black, Ground from J116-3
J2-6 Not Used
J2-7 Not Used
J2-S Not Used
J3-1 Violet, G.I. return to coin door
J3-2 White-Violet, G.I. 6.SVAC to coin door
J3-3 Black, Ground to coin door
J3-4 Orange-Brown, dedicated switch row 1 to coin door
J3-5 Not Used
J3-6 Orange-Black, dedicated switch row 3 to coin door
J3-7 Orange-Green, dedicated switch row 4 to coin door
J3-S Orange-Blue, dedicated switch row 6 to coin door
J3-9 Orange-Violet, dedicated switch row 7 to coin door
J3-10 Key
J3-11 Orange-Gray, dedicated switch row S to coin door
J3-12 Green-Red, switch column S to coin door
J3-13 White-Brown, switch row 1 to coin door
J4 Not Used
J5 Not Used
Ll)
-,
o
o
o
o
o
o
o
•
o
C>
J6-1 White-Red, switch row 2 to cabinet
J6-2 White-Orange, switch row 3 to cabinet
J6-3 White-Yellow, switch row 4 to cabinet
J6-4 Red-Gray, lamp row S to cabinet
J6-5 Key
J6-6 Green-Red, switch column 2 to cabinet
J6-7 Green-Brown, switch column 1 to cabinet
J6-S Green-Brown, switch column 1 to cabinet
P.c.
Board Legend
J1-J6 Coin Door InterfaceBoard
J1xx Power DriverBoard
J2xX CPU Board
J5xx Audio Board
J6xx Dot MatrtxControllerBoard
J9xx FllptronIe II Board
DOCTORWHO 3-19
