POWER DRIVER BOARD CONTINUED ...
J11S-1 Yellow-White, 6.8VAC from transformer secondary
J11S-2 White-Brown, 6.8VAC from transformer secondary
J11S-3 White-Brown, loop from J11S-2
J11S-4 White-Orange, 6.8VAC from transformer secondary
J 11S-S White-Yellow, loop from J 11S-6
J11S-6 White-Yellow, 6.8VAC from transformer secondary
J11S-7 Orange, 6.8VAC from transformer secondary
J11S-8 Orange, 6.8VAC loop from J11S-7
J11S-9 Key
J11S-10 Green, 6.8VAC from transformer secondary
J11S-11 Brown, 6.8VAC from transformer secondary
J11S-12 Brown, 6.8VAC 100pfromJ11S-11
J116-1 Key
J116-2 Gray-Yellow, +12VDC to coin door; J2-4
J 116-3 Black, Ground to coin door; J2-S
J116-4 Not Used
J117-1 Key
J 117 -2 Gray-Yellow, +12VDC to J606-7
J 117-3 Black, Ground to J606-3
J 117 -4 Gray, +SVDC to J606-S
J118-1
J118-2 Gray-Yellow, +12VDC to backbox
J118-3 Black, Ground
J118-4
J119-1 White-Violet, 6.8VAC G.I. to coin door; J2-2
J119-2 Key
J119-3 Violet, Return G.I. to coin door; J2-1
J120-1 Not Used
J120-2 Not Used
J120-3 Yellow, Return G.I. to playfield
J120-4 Key
J120-S Green, Return G.I. to playfield
J120-6 Violet, Return G.I. to playfield
J120-7 Not Used
J120-8 Not Used
J120-9 White-Yellow, 6.8VAC to playfield
J120-10 White-Green, 6.8VAC to playfield
J120-11 White-Violet, 6.8VAC to playfield
J121-1 Brown, Return G.I. to insert
J121-2 Orange, Return G.I. to insert
J121-3 Yellow, Return G.I. to insert
J121-4 Key
J121-S Green, Return G.I. to insert
J121-6 Violet, Return G.I. to insert
J121-7 White-Brown, 6.8VAC to insert
J121-8 White-Orange, 6.8VAC to insert
J121-9 White-Yellow, 6.8VAC to insert
J121-10 White-Green, 6.8VAC to insert
J121-11 White-Violet, 6.8VAC to insert
J122-1 Not Used
J122-2 Not Used
J122-3 Blue-Orange, Sol 27, Special 7 Drive
J122-4 Blue-Yellow, Sol 28, Special 8 Drive
J122-S Not Used
J122-6 Not Used
J122-7 Key
J122-8 Not Used
J122-9 Not Used
J123 Not Used
J124-1 Not Used
J124-2 Not Used
J124-3 Not Used
J124-4 Key
J124-S Not Used
J12S-1 Black-Brown, Sol 17 to insert board flashlamp
J12S-2 Black-Red, Sol 18 to insert board flashlamp
J12S-3 Black-Orange, Sol 19 to insert board flashlamp
J12S-4 Key
J12S-S Black-Yellow, Sol 20 to insert board flash lamp
J12S-6 Blue-Green, Sol 21 to insert board flashlamp
J12S-7 Blue-Black, Sol 22 to insert board flashlamp
J12S-8 Blue-Violet, Sol 23 to insert board flashlamp
J12S-9 Blue-Gray, Sol 24 to insert board flash lamp
J126-1 Black-Brown, Sol 17 to playfield flashlamp
J126-2 Black-Red, Sol 18 to playfield flash lamp
J126-3 Black-Orange, Sol 19 to playfield flash lamp
J126-4 Black-Yellow, Sol 20 to playfield flash lamp
J126-S Blue-Green, Sol 21 to playfield flash lamp
J126-6 Blue-Black, Sol 22 to playfield flashlamp
J126-7 Blue-Violet, Sol 23 to playfield flashlamp
J126-8 Blue-Gray, Sol 24 to playfield flashlamp
J126-9 Key
J126-10 Not Used
J126-11 Not Used
J126-12 Not Used
J126-13 Not Used
J127-1 Brown-Black, Sol 9 to playfield coil
J127-2 Key
J127-3 Brown-Red, Sol 10 to playfield coil
J127-4 Brown-Orange, Sol11 to playfield coil
J127-S Brown-Yellow, Sol 12 to playfield coil
J127-6 Brown-Green, Sol 13 to playfield coil
J127-7 Not Used
J 127 -8 Brown-Violet, Sol 1S to playfield coil
J127-9 Brown-Gray, Sol 16 to playfield coil
P,C, Board Lagend
J1-J6 Coin Door Interface Board
J1
Xl(
Power Driver Board
J2xx CPU Board
J5xx Audio Board
J6Xl(
Dot Matrix Controller Board
J9xx FllptronIe II Board
DOCTORWHO 3-21
