B-9414
Jet Bumper Assembly
r- ••.•
: <.
I
.••.••..
I
••..••..
•...'1
I
I
I
I
I
I
A-941 5-2
Jet Bumper Coil Assembly
I
I
I
,
I
~
r
JWn
fart
Number
Description
111m
part
Number
Description
1.
A-4754
Bumper Ring Assembly
1.
B-7417
Bracket & Stop Assembly
2.
03-6009-A5
Bumper Base, White
2.
01-1747
Coil Retaining Bracket
3.
03-6035-5
Bumper Wafer, White
3.
01-5492
Armature Link, Steel
4.
03-7443-5
Bumper Body, White
4.
01-5493
Armature link, Bakeltte
5.
10-7
Spring
5.
02-3406-1
Coil Plunger
6.
24-8776
Socket-Wedge Base
6.
10-326
Armature Spring
7.
24-8768
Bulb #555 (S.3V., 0.25A.)
7.
AE-26-1200
Coil Assembly
8 .
4006-01017-04
Mach. Screw, 6-32 x
1/4"
• Associated Parts:
9.
03-7066
Coil Tubing
8.
03-9007-12
Jet Bumper Cap
(Starburst, Raised) 2 Used
DEMOL"'ON MAN 2-20
