NOTES:
1. Heat sink compound
must
be applied between transistor and heat sink.
2. Observe index mark on integrated circuit, polarity of capacitors and diodes,
and position of transistors.
3. The view of Q5 and its related heat sink and hardware is from the bottom of
the heat sink, to clarify installation
Power
Supply
pin
0-8345-557
llam Part
Ha.
Ckt Designator
Description
1 5765-09466-01
Bare P. C. Board
2 50 13-09426-00
R7
Resistor, 2.15K, 1%,
1/4w,
Melal Film
3
5013-09427-00
R8
Resistor. 4.99K. 1%,
114w, Metal Film
4
5010-09428-00
Rll
Resistor, 1.5K, 2%,
1/4w,
C.
Film
5
5010-09085-00
Rl0
Resistor, 1.5K, 5%, 114w
6
501 0-0 9541 -00 R9
Resistor, 2.7K, 2%,114w
7 5010-09508-00
Rl2
Resistor, 270n. 2%,
1/4W,
C. FRm
8
50 12-09429·00
R13
Resistor, 0.120,
5%,5w
9
5010-09536·00
Rl,
R4
Resistor, 39K, 5%,1 w
10 5010-09061-00
R2,
R5
Resistor, 6800, 2w
11 5010-09069-00
R3,R6
Resistor, 330K, 5%, 112w
12 5040-09419·00
Cl0
Capador,
18.000 mid, electr,
20v, axial
13 5040-09420-00
C9
Capac~or,
1000 mfd, electr,
25v, axial or radial
14
5040-09423-00
C12
Capac~or, 330 mfd, electr,
10v,radial
15 5043-9065-00
C15
capacacr,
470 pfd
16 5040-9053-00
c i,
C3
Capac~or.
100 mfd, electr,
150v
17 Not Used
18 5043-09072-00
C2, C4
Capac~04',
0.1
mid,
500v,
disc
19 504J ·09446-00
C14
Capacitor, 0.1 mid,
50v,
disc
20
5070-06258-00
D1, D5, 06
Diode, 1N4001
21 5070-09054-00
03,04
Diode, 1 N4004
22 5075-09059-00
lA1,
ZR3
Zener, 1 N5990,
3.9'1,5%
23 5075-09060·00
ZR2,ZR4
Zener, 1N4764 , 100v, 5%
24 5460-09424-00
ICl
IC, Volt. Reg., MC1723C
25 Not Used
26 5040-09421-00
C7
Capac~or,
100 mtd,
25v,
radial
27
5040--09422-00
C8
CapacHor. 47 mId, 50v, radial
Item Part No.
Ckt Desfgnator
28 5164-12154-00
01
29 5164-09056-00
Q4
30
5194-12155-00
03
31 5194-09055-00
02
32 5162-09425-00
05
33 Not Used
34 5791-09074-00
3J6
35 5791-09027-00
3J6
36 Not Used
37 5791-09067-00
3J5
38
Not Used
39
Not Used
40 H-l1065
3J9
a) 5791-09400-00
b)
5820..1)9080-00
41 5791-09068--00
3Jl
42 5321-0917B"()()
43
5731-06314-00
F2
44 Not Used
45 Not Used
46
Not Used
47 Not Used
48 5700-09445-00
49 5701-09052-00
50 Not Used
51 5824-09428-00
TP2 - TP4
52 5100-09418-00
BRl
53 5705-09042-00
54 03-7947
55 4005-01016-07
56 Not Used
57 4701-00023-00
58 4405-01117-00
59 20-9229
60 Not Used
61 5731-09342-00
Fe, F5
BIG
GUNS 37
o
@o
o
40
Description
Transislor,
MJEl5030.
NPN
Transistor,
MPSD02, NPN
Transistor,
MJE15031,
PNP
Transistor,
MPSD52, PNP.
Transistor,
2N6057, NPN
Connector,
15 pin (Hdr)
Connector,
9 pin (Hdr)
Connector,
6 pin
(Hdr)
Cable/Connector
Assembl~
Connector shell
Connector pin
Connector,
12
pin (Hdr)
Fusehotder
Fuse,4A,250v,S-B
Socket
Mica Insulator
Terminal, #1502-1 (Test Post)
Bridge Rectifier, 35A, 100V
Heat Sink
Tie Wrap
Mach. Screw, 5-40 x 7116, RH
Lockwasher,
#5, split
Hex Nut, 5-40
Heal sink Thennal
Compound
Fuse, 7A, 250V,
SoB
