Alphanumeric Display Unit Board
including pIn 0-"609
&
associated parts
Part No.
Ckt Deslgnalor
Description
Part No.
Ckt Designator
Descrlpllon
5760-1:2134-00
Bare
P. C,
Board
5010-O8773'{)0 R1, R2,R8,R20,R:23 Resistor, 1BK,
1/4
W,
5%
5680-08968-00 U8,U13,U14.U16
IC. AnodelDig~ Driver,
501
0-10927'{)0 R4, RS.Rl B, A19.
Resistor, 8,2 K, 112
W,
5%
UDN6118A or6184
R21, R22, R24, R25
5310-09882-00 U4-U7
IC, Quad NOR, 40018
5010-10258-00 R27. R28, RaO- R35 Resistor, 1 M, 114w, 5%
5680-08969-00 U11, U12, U15
IC. Calhode Seg, Driver,
SO10-08981-00 R3, RS, R7, R9, R10, Resistor, 10 K.
1/2
W,
5%
UDN7180A
Rl:2 - R17
5310-09153-00 Ul - U3, U9, U10 IC, Hex Buffer, 4050
5010-08772 -00 Rl1
Resistor, 15 K, 114w, 5%
5075-09135-00 01
Zener diode, lN4740A, 10V, 1
W
5670-10873-00 DSPY1, OSPY2
Display, 7 -characier, NN
5040-09343-00 C4
Capacitor, 10 utd., 25v, ±5%,
5670·09439-00 DSPY3. DSPY4
Display, 7-charaCler. 7-segmenl
Axial
5791-10851 -00 Jl
Connector, 26 pin (Hdrl, AI. Angle
5043-08996-00 C3
Capacitor. 0.1 utd. 50v, ±20%,
5791-10869-06 J2
Connector, 6 pin (Hdr). RI. Angle
Axial
5791·10869-09 J3 - J5
Connector. 9 pin (Hdr), At. Angle
5043-08980-00
c
t,
C2, C5 - C7
Capacitor, 0.01 uld,
50v.
Axial
03-8088-1
Support
Support, Display
5019-10387-00 SR1 - SR3
SIP. 18 K. 9R. lOP, 5%
a
BIG
GUNS 36
Display Characters Segment DeSignations
