i •
•
-
-::
•
•
20
VAC
1
2
6
9
3
6
4
8
7
7P6
1
- 2
- 6
9
3
- 6
- 4
- 8
...IIA'___~
7
mv Varfetor: &011-Ot083-OO
130Vvert_or: &011-01044-00
4A, .-8 fu •• : 11131-OeS14-00(for 22OV) 8A"No8F_: 5130-082624-00 Itor 1111V)
[] a.Lower the playfield. Adjust leg levellers for proper
playfield level (side-to-side). Rest your level on the playfield,
not the cabinet nor the playfield cover glass .
[ ] 9.Adjust leg levellers for a playfield pitch (incline) of seven
degrees. Rest your level on the playfield, not the cabinet
nor the playfield cover glass. To maintain step 7 and a set-
tings, tighten the nut on each leg leveller shaft.
CAUTION
Playfield pitch adjustments can affect the operation of the
plumb bob tilt. The plumb bob tilt is Inside the cabinet.
After completing playfield pitch adjustments, set this
mechanism for desired operation.
[] 10.Move the game into the desired location. Recheck
the level and pitch angle of the playfield.
[ ] 11.Check that the required number of balls are installed
in the game.
TRUCK STOP
uses three balls.
[] 12.Clean and reinstall playfield glass. Prepare the game
for play .
1-7
