[ ] 5.Raise the hinged back box upright. Latch the clamp on
the back of the cabinet and backbox.
[] 6.Unlock the backbox. Remove the back box glass. To
avoid scratches, carefully store the glass. Install mounting
bolts and flat washers through the bottom holes of the back-
box. The bolts mate with threaded fasteners in the cabinet
and secure the backbox.
"
..
WARNING
NEVER transport a pinball game with the hinged backbox
erect. Prevent equipment damage and personal injuryl
When you lower the backbox, insert a layer of protective
material between cabinet and backbox.
•
[ ] 7.Extend each leg leveller Slightly below the leg bottom.
All four foot pads should be extended about the same dis-
tance. Remove the cabinet from its support and place it on
the floor.
[ ] 8.Raise the playfield and examine the following areas ...
•
• Are cables clear of moving parts?
.Have wires come loose during shipment?
.Is there loose solder or other foreign material in
switches or sockets? Such material may come loose in
shipment. It could short switches or lamp sockets.
to
.Is the power transformer jumpered for local line
conditions? Transformer plug wiring must correspond
to location voltage. See the table below. Also examine
the BACKBOX WIRING SCHEMATIC .
• Are coils properly soldered? Vibration in shipment may
cause loss of contact.
-.
•
1-6
