WPC operates on a Menu System . To enter the Menu System, open the coin door and press the
Begin Test button. The displays show the Game lD. Mode. Press the Enter button and the Main
Menu appears. Press the Start button for HELP at any time.
The Main Menu allows you to choose from several main categories, which in turn lead to other
menus to choose from.
MaipMenU
B. Bookkeeping Menu
P. Printouts Menu
T. Test Menu
U. Utilities Menu
A. Adjustments Menu
To cycle through the Main Menu press either the Up button to move forward or, the Downbutton to
move backward through the menu. Activate any selection from the Main Menu by pressing the
Enter button when the desired selection appears in the displays . To return to the Attract Mode while
viewing the Main Menu press the Escape button.
If you choose to enter the Bookkeeping Menu, press the Enter button when the name appears in the
displays. under the Main Menu. The Bookkeeping Menu gives you several audit groups to choose
from. Press the Up or Down button to cycle through the Bookkeeping Menu. Press the Enter button
to activate the desired Bookkeeping Group when that group appears in the displays.
B. Boo"mnipg Men»
B.l
Main Audits
B.2 Earning Audits
B.3 Standard Audits
BA
Feature Audits
B.5 Histograms
B.6 Time-Stamps
Once you have entered the desired Bookkeeping Group ,press the Up or Down button to cycle through
the available audits in that group. Audits cannot be set , they can only be cleared by using Ul and
U2 from the Utilities Menu.
Press the Escape button to return to the Bookkeeping Menu . Press the Up button to advance to the
next desired Bookkeeping Group. (or press the Down button to return to a previous group). Press the
Enter button to activate that group . If you chooseto return to the Main Menu press the Escape button
again.
One-Button Audit System
Information from the Bookkeeping Menu is obtainable directly from the Attract Mode. Repeated
pressing of the Enter button, while in the Attract Mode. will cycle through a11of the game audits .
2-3
