(With Related Parts)
B-nS2-L
(Shown - 20
used)
and
B-nS2-R
(16
used)
Switch Actuator Wires
12-6470-L &
-R
I
#8 Solder Lug - Flat
7
J
5825 -06523-00
r-
I
~
I
!
Diode 1N
4001 ---
5070-06258-00
it
'---
Switch Limit Bracket
01-3797-2
Switch Notes:
1. SW-1A-128-L - Single Make Switch with side lug mounted left, used with B-7752-L (14 per game).
2. SW-1A-128-R • Single Make SWitch with side lug mounted right, used with 8-7752-R
(10
per game).
3.
SWotA-129-L • Double Make Switch with side lug mounted left, used with B-7752-L (2 per game).
4.
SWot A-129·R - Double Make Switch with side lug mounted right, used with 8-7752-R
(2
per game).
8-22
