RevoMng Flash
lamp
Assembly
C-10933-1
Used on Shuffle Inn (10001)
Item Part Number
Description
1
B·10934-2
Motor Plate
&
Bracket Assembly
a)
01-8219·1
Mounting Plate, Motor
b)
20-9503
Pem Nut 4-40 (2 used)
~
c)
B-10916-2
Socket
&
Bracket Assembly
d)
07-6688-4
Rivet, 5132x .147 (2 used)
~
2 14-7939
Motor, 24V, 100 RPM
3 4004-01003-05
MS 4-40 x 5116P-PH-S (2 used)
-
,:;,---
4 8·10917-1
Reflector Assembly
--
.....- -=.J ___ -.....
a)
01-8218
Reflector
/ '
- -
- .. . .. ... .
< ,
/'
'"
b)
01-8221-1
Mounting Bracket
c)
07-6688-16N
Rivet,
1/8
x .218 (2 used)
d)
02-4239
Collar, Motor Shaft
5 4006-01076-04
SS 6--32x
1/4
SH-CP
6
03-7869-1
Snap Bushing
7 HW-30018-9
Wire, 18AWG White (24-)
8 5820-09080-00
Male Crimp Pin (2 used)
03-7981
9 5791-09111-00
3 Position Connector
light Dome. Tr. Red
10 03-7520-2
Nylon Ty~Wrap (4 used)
(Mtd. on top of Backbox)
11 24-8771
#1683 Bulb 28V
ELECTRONICS GAMEB.INC.
8-21
