6-14
Mini-Micro Switches
&
Associated Assemblies
Switch
Used On
Diner
Whirt
BlCats Roller
Part Number
Assembly Part No.
571
574
575
576
Game and Part Quantity
5647-12073-07
0-13663 Main Ramp
1
(See p. 3-20)
5647-12073-08
A-11680 Sw/Brkt Assy.
1
1
1
(Used in conjunction wiUl
Switch Plate Assembly
B-8925. See p. 4-23)
5647-12073-11
A-13487 Sw. Gate Assy.
1
(See p. 4-22)
A-13669 Sw. Gate Assy.
2
(See p. 4-22)
0-13129 Rear Ramp Assy.
1
(See p. 3-24)
0-13663 Main Ramp Assy.
1
(See p. 3-20)
5647-12073-17
0-13660 Coffee Cup Assy.
1
(See p. 5--31)
I
5647-12073-21
0-12975 Center Ramp Assy.
1
(See p. 3-26)
0-13191 Wire Ramp Assy.
1
(See p. 4-7)
0-13663 Main Ramp Assy.
1
(See p. 3-20)
0-13666 Left Ramp Assy.
1
(See p. 3-22)
R-t2974 Left Ramp Assy.
1
(See p. 3-27)
R-13190 Left Ramp Assy.
2
(See
p.
3-25)
Note: For Mini-Micro Switches wiUl wireforms. see Section 4.
