Page 565 - Williams RED Parts Catalog 16-9190-B

Micro Switches and Associated Assemblies
Switch Used On Diner Whirl Bleats Roller
Part Number Assembly Part No. 571 574 575 576
Game and Part Quantity
5647-09957 -00 B-8925 Sw. Plate Assy. 2 2 2
(See p. 4-23 for placement)
5647-12001-00 B-11304 Ramp Lift Mech. 1
(See p. 5-34)
B-11304-2 Ramp Lift Mech 1
(See p. 5-28)
5647-12133-08 A-12010 Sw.lBrkt. Assy. 1 2 2 2
5647-12133-11 A-9481-R Sw.lBrkt. Assy. 2 1 1
5647-12133-12 A"10417 Sw./Brkt. Assy. 1 1 1 1
5647-12133-13 574-PL ("Sling" Switch) 2
Note: For Micro Switches with wireforms, see Section 4.
5647-09957-00 5647-12001-00 5647-12133-08
5647-12133-11 5647-12133-12 5647-12133-13
6-13
