Unique Assemblies - cont'd
HURRICANE (50012)
3
2
Ferris Wheel Assembly
A·14741
5
Item Part Number
Description
1 A-14740
Main Mounting Plate Assembly
2 03-8124
Front Ferris Wheel, Red
3 03-8125
Wheel Cover, Clear (2 used)
4 A-14593-1
Motor Assembly
5 23-6663
Drive Belt
6 03-8086
Pulley
7 03-8281
Pulley
8 02-4290
Collar
9
A-14737
Pulley Bracket Assembly
10 A-14743
Mini-Ramp Assembly
For reference only:
11 03-8126
Drive Belt Washer
12 4006-01017 -05 Sems #6-32 x
5/16
P-RH (2)
31-2-50012-3A Decal applied to Rear Wheel
13 A-14738
Left Wheel Guide Assembly
31-2-50012-38
Decal applied to Rear Wheel
14 20-8712-25
"E" Ring (3 used)
31-2-S0012-3C Decal applied to Rear Wheel
15 4106-01033-08
SMS #6 x 1J2 PH (4 used)
31-2-50012-30
Decal applied to Rear Wheel
16 4700-00072-00
FW
17/64
id x 1
f2
od (3 used)
31-2-50012-S
Rear Wheel Cover Decal
17 4008-01 076-06
SS #8-32 x 318
18 4700-00007-00
FW 5/32 id x
7116
od (2 used)
31-2-50012-3E Decal applied to Front Wheel
19 4006-01017-04
Sems #6-32 x
1/4
P-RH (4)
31-2-50012-3F
Decal applied to Front Wheel
20 03-8126-1
Drive Belt Washer
31-2-S0012-3G Decal applied to Front Wheel
21 03-8124-1
Rear Ferris Wheel, Blue
31-2-50012-3H Decal applied to Front Wheel
22 4006-01003-03
Sems #6-32 x
3/16
P-PH (2)
31-2-50012-4
Front Wheel Cover Decal
