(50012)
Unique Assemblies For Specific Games
(f_)
Item Part Number
Description
1 A-14741
Ferris Wheel Assembly
2 0-11335-'
Ball Popper Assembly
3 A-14750
Disc & Motor Assembly
(Located on Insert Bd)
Ball Popper Assembly
D~11335-1
(See p. 5-44 for drawing)
Item Part Number
Descrlpth::m
1 03-8053
Ball Popper Cap
2 Not Used
3 20·9314-7
Dowel Pin,
3/32
X
1/2"
4 AE-24-900
Coil Assembly
5 01-9794
Mounting Bracket
6 10-135
Spring
7 A·11336
Armature Assembly
8 23·6420
Rubber Grommet
9
4008-01017·04
MS #8-32 x
5/16
10 B-11631
Bracket Assembly
11 03-7067
Coil Tubing
ELECTRONICS GAMEB.INC.
5-61
