Unique Assemblies - cont'd
THE MACHINE (50002)
~
/
/
/
/
Helmet Assembly
A·14508
Item Part Number
Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
03-8548
03-8149-9
C-13337
03-8022-4
03-6047-1
03-6047-3
4106-01001-16
4006-01003-12
4700-00070-00
31-2-50002-'
H-1442S-1
A-14410
A-14412
4406-01128-00
03-7722-4
03-8063-6
03-8063-4
Helmet
Mini Dome.
Tr.
Red
Single Flashlamp Assy.
Spacer.
1/4"
Lg.
Spacer.
1/4"
19.
Spacer.
1/2"
19.
Sh. Metal Screw. #6 x
t"
Mach. Screw. 6-32 x
3/4
Flatwasher,
3/16
x
S/8
x 16ga.
Decal
Helmet Cable
a-Lamp Board
8-Lamp Board
Nut, 6-32 KEPS
Clip,
1/4"
Yellow
light
Bulb Sleeve
Red
light
Bulb Sleeve
ELECTRONICS GAMEB.INC.
5-49
