Page 340 - Williams RED Parts Catalog 16-9190-B

SEO Version

(50018)
Wireform and Ball Gate Locations
Upper PlayfieJd
Ilem Pan Number
Description
1 12-7063
2 12-6466-45
3
12-7051
4
12-7052
5
A-16099
6 12-7049
7 12-7044
Bottom Arch Wire Fence
Wire Ball Guide
4-5/8-
Boulder Wire Guide
Boomera.ngWire Guide
Dual Ball Gale Assembly
aall Popper Wire Ramp
Righi Wire Ramp Shoot
Under Bottom Arch Runway:
8
8-8925
a)
A-8645
b)
A-5844-45
c)
A·5844-44
9 12-6542
Trough Switch Plate Ass'y
Rollover Wire/Srkt Ass'y
Rollover Wire/Brkt Ass'y
Rollover Wlre/Srkt ASs'y
aall Return Gate Wire
4-4i
