Page 338 - Williams RED Parts Catalog 16-9190-B

?·!!;EIIWIYqp {50004}
Wireforms and Ball Gate Locations
Item Part Number
1 12-6842
2 A-15102
3 12-6466·30
4 12-7017
5 12-6466-47
6 12-7034
7 A-15558-1
8 12-6466-9
9 12-6466-14
10 A-15103
11 A-15135
12 12-6466-12
Under Bottom Arch Runway;
13 8-8925
a) A-8645
b) A-5844-45
c) A-5844-44
14 12--6542
t
Description
Bottom Arch Wire Fence
Left Wire Ramp
Wire Ball Guide 9-1/4-
Wire Ban Guide
Wire Ball Guide 5-7132·
Wire Ball Guide
1-Way Ball Gate Ass'y
Wire Ball Guide 2-1/4-
Wire Ball Guide 3-112-
Right Wire Ramp
Ball GuidelGate Assembly
Wir. Ball Guide 3-
Trough Switch Plate Ass'y
Rollover WirelBM Ass'y
Rollover WirelBrkt Ass'y
Rollover WirelBrkt Ass'y
Ball Return Gate Wire
4-49 ELECTRONICS GAMEB.INC.
