Page 333 - Williams RED Parts Catalog 16-9190-B

Wireform and Ball Gate Locations
(50007)
Item Part No. Description
1 12-6871 Anti-Bif Wire
2 12-6842 Bottom Arch Fence
3 12-6893-1 lower Ramp Wire 6-3/S"
4 12-6893 Upper Ramp Wire 7-1/8R (2)
5 8-12267 1-Way Ball Gate Assembly
6 8-13850-1 Ball Gate/Switch Ass'y (3)
7 A-11760-2 1-Way Ball Gate Assembly
8 A-13863 1-Way Ball Gate Assembly
Under Bottom Arch:
9 A-8645 Rollover Wire & Brkl Ass'y
10 A-5844-44 Rollover Wire & Brkt Ass'y
11 A-5844-45 Rollover Wire & Brk! Ass'y
12 12-6542 Trough Baffle Wire
ELECTRONICS GAMEB.INC.
