(50003)
Wireform and Ball Gate Locations
Item Part No.
Description
12-6950
Bottom Arch Fence
2 A-9572
Post
&
Gale Assembly
3 12-6466-9
Wireform 2-1/4"
4 A-13897
Lower Wire Ramp Ass'y
5 A-138gB
Upper Wire Ramp Ass'y
6 A-14373
Ball Gate Assembly
7 A-1337B
Ball Gate Assembly
8 A-12120
Ball Gate Assembly
9
12-6466-7
Wireform 1-3/4" (2 used)
10 A-14196
Ball Gate Assembly
11 12-6466-2
Wireform
1/2"
12 12-6466-5
Wireform 1-1/4"
Under Bottom Arch:
13 A-8645
Rollover Wire
&
Brkt Ass'y
14 A-5844-44
Rollover Wire
&
Brk! Ass'y
15 A-5844-45
Rollover Wire
&
Brkl Ass'y
16 12-6542
Trough Baffle Wire
Note: All straight wireforms are not shown.
See p. 4-14 for usage.
4-4b
