Page 33 - Williams RED Parts Catalog 16-9190-B

SEO Version

TERMINATOR 2
(50013)
Playfield Circuit Board Locations
(Underside View)
Backbox Circuit Board Locations
13
--0
k@
_.
l -
t-@)
@-
~
.
_ _
.
Display/Speaker
Panel
(Rear View)
Item Part Number
Description
Item Part Number
Description
A-14516
4-Lamp PCB Assembly
12 A-12742-50013 WPC CPU Board Ass'y
2
A-14517
5-Lamp PCB Assembly
13 A-12738-50003 WPC Audio Board
3 A-1451B
4-Lamp PCB Assembly
14 A-14039
Dot Matrix Controller Bd.
4 A-14519
5-Lamp PCB Ass'y (2)
15 A-12697-1
Power Driver Board
5 A-14s20
6-Lamp PCB Ass'y (2)
6 A-14689'"
WPC Coin Door PCB
16 5901-12784-00 Dot Matrix Display/Driver
7 A-14521
s-Larnp PCB Assembly
8 C-13361
3-Lamp PCB Assembly
9 A-13B92-2
Motor Regulator PCB
10 C-12709
3-Lamp PCB Assembly
11 C-12000
3-Lamp PCB Assembly
0
B-12224
Single Lamp PCB (9)
*Mounted on left wall of Cabinet.
ELECTRONICS GAMEB.INC.
1-4e
