HURRICANE (50012)
Playfield Circuit Board locations
(Underside View)
Backbox Circuit Board Locations
0-
13
-
®-
'--
-
r-®
Display/Speaker Panel
(Rear View)
1-4d
Item Part Number
Description
A-13901-3
Opto Ramp Switch Bd.
2 C-13911
3-Lamp PCB Assembly
3
C-13205
3-Bank Opto Board
4 A-14847
6-Lamp PCB Assembly
5 A-14848
5-Lamp PCB Assembly
6 A-14846
6-Lamp PCB Assembly
7 A-14689·
WPC Coin Door Interface
8 A·14978
5-Lamp PCB Assembly
9 C-12877
4-Lamp PCB Assembly
10 A-14849
4-Lamp PCB Assembly
11a A-14845
3-Lamp PCB Assembly
(Mtd. above Playfield on A-14708 Ramp Ass'y)
11 A-14423-1
Relay Board
C-13337
Single Flash PCB (6)
"Mounted on left wall of Cabinet.
Insert Board
(Viewed in open position)
o
[ ] 0
[ J
Item Part Number
Description
12 A-12742-50012 WPC CPU Board Assembly
13 A-12738-50012 WPC Sound Board Ass'y
14 A-14039
Dot Matrix Controller Bd.
15 A·12697-1
Power Driver Board
16
5901-12784-00 Dot Matrix DisplaylDriver
