Page 218 - Williams RED Parts Catalog 16-9190-B

(50004)
Ball Guide and Ramp Locations
Item Part Number Description
1 A·15456·2 Left Return Frame
2 A-15088 Ball Guide Assembly
3 A·15120 Ball Guide Assembly
4 A·15301 Accelerator Ramp Ass'y
a) A-15296 Entrance Ramp Weldmant
b) 01-10613 Center Wall Bal Guide
c) A-15297 Entry Ramp Assembly
d) A-15300 Ramp Tray
e) A-15293 Retum Ramp Assembly
5 A-15291 Ball Guide Assembly
6 A-15083 Ball Guide Assembly
7 A-15101 Ramp Assembly
a) A-15081 Pivot Floor Weldment
b) A-15076 Ramp Weldmant
8 A-15086 Ball Guide Assembly
9 01-10471 Ball Guide
10 A·15084 Ball Guide Assembly
11 01-10470 Ball Guide
12 A-1S087 Ball Guide Assembly
13 01-10469 Ball Guide
14 A-1S082 Ball Guide Assembly
15 A-15085 Ball Guide Assembly
16 A-15135 Ball Guide/Gate Assembly
17 A-15456-1 Right Return Frame
Under Bottom Arch A-13204-50004:
18 8-8623 RunwaylBatUe Assembly
19 01-3569-1 Ball Return Runway
20 01-10599 Runway Ban Guide
