Under Bottom Arch A-13204-50001:
(50001 )
Ball Guides and Ramp
locations
hem Part Number
1 A-15306-2
2 01-11095
3
01-11091
4 A-16250
5
01-11100
6 01-11093
7
01-11160
8
01-11097
9 A-16145
10 A-16251
11
A-16144
12 A-16141
13
A-1627a
14 A-16260
15 01-11099
16 01-11096
17 01-11094
18
A-16415
19
A-16142
20 01-11098
21 A-16247
22 01-11092
23 A-15306-1
24 A-16253·
25
A-16252·
26 8-8623
27 01-3569-1
28 01-10599
·Mounted under Playtield
Description
Left Return Frame
Ball Guide
Ball Guide
Main Ramp Assembly
Ball Guide
Ball Guide
Ball Deflector (3)
Ball Guide
Ball Guide Assembly
Upper Center Ramp Ass'y
Ball Guide Assembly
Ball Guide Assembly
Center Ramp Entry Ass'y
Coffin Plate Assembly
(See
p.
5-70)
Ball Guide
Ball Guide
Ball
Guide
Entry Ramp Assembly
Ball Guide Assembly
Ball Guide
Entry Ramp Assembly
Ball Guide
Right Return Frame
lower Left Ramp Ass'y
lower Center Ramp Ass'y
RunwaylBaffle Assembly
Ball Return Runway
Runway Ball Guide
ELECTRONICS GAMEB.INC.
3-4f
