Page 80 - BallyMidway GREY Parts Catalog 16-9562-A

Cable Assemblies - cont'd
Crea Judge TwiZ Pop
Part Number Description 20018 20020 50020 50022
Game and Part Quantity
H-16600 Clock Cable x
H-16603 Opto Cable x
H·16605 Hairpin Ramp Cable x
H-16607 Gumball Opto Cable x
H-16609 Left Magnet Xmit Cable x
H-16610 Left Ramp Cable x
H-16611 Diverter Cable x
H-16613 lockup Opto Cable x
H-16614 Bottom Magnet Opto Cbl x
H-16785 Right Magnet Opto Cbl x
H-16810 50 Volt Cable x
H-16884 Speaker Panel Cable x
H-16896 Playfield Switch Cable x
H-16897 Playfield Lamp Cable x
H-16898 Playfield Solenoid Cable x
H-16899 Playfield Opto Cable
H-16900-1 Cabinet Cable x
H-16901 Planet Cable x
H-16902 Crane Cable x
H-16904 Insert Cable x x
H-16951 Cabinet Switch/Lamp Chi x
H-16952 Subway Switch Cable x
H-16953 Right Ramp Exit Cable x
H-16960 Crane Motor Cable x
H-16961 Plane Motor Cable x
H-16962 left Pursuit Cable x
H-16963 Right Pursuit Cable x
H-16993 Stake Out Cable x
H-16994 Pick Prize Cable x
H-16995 Right lane Opto Cable x
H-16996 Right Lane Opto Cable x
H-16997-1 left Ramp Cable x
H-17005-2 Cabinet Cable x
H-17019 Dixie-Mars Interconnect Chi x
H-17037 Left Ramp Exit Cable x
H-17070 Single G.!. Cable x
H-17071 Right Ramp Cable x
H-17072 Crane Release Cable x
H-17196 Cabinet Tilt Cable x
1-30 (j]af6; /MIDWAY
