Page 79 - BallyMidway GREY Parts Catalog 16-9562-A

Cable Assemblies
Crea Judge TwiZ Pop
Part Number Description 20018 20020 50020 50022
Game and Part Quantity
H~11835 Knocker Cable x x x x
H~13870 Black Jumper Cable x x
H~14584 Dot Matrix Displq Pwr Cbl x x x
H~14790 A.C. Cable x x
H~14792~1 A.C. Jumper Cable x x
H·14792·2 A.C. Jumper Cable x x
H-15011 Speaker Panel Cable x
H-15476 Logic Power Cable x x x x
H-15478 Tilt Mechanism Cable x x
H-15724 Cabinet Button Cable x
H·15736 Secondary Cable x x x x
H-15860 Playfield SWitch Cable x
H·15861 Playfield Lamp Cable x
H-15862 Playfield Solenoid Cable x
H·15863 Cabinet Cable x
H·15864 Insert Cable x
H·15865 Hologram Cable x
H·15866 Ramp Switch Cable x
H-15867 Left Ramp Switch Cable x
H·15868 Billboard Cable x
H-15869 Billboard Lamp Cable x
H-15870 Bowl Lamp Cable x
H-15871 Chase Light Cable x
H-15872 Reflector Cable x
H-16037 Motor Cable x
H-16115 Right Billboard Cable x
H-16213 Front Chase Light Cable x
H-16214 Center Chase Ught Cable x
H·16229 Playfield Opto Cable x
H-16236 Back Panel Cable x
H-16293-1 24" Receiver Cable x
H-16294 24· Transmitter Cable x
H-16335 Playfield Opto Cable x
H-16423 OPIO Switch Cable x
H-16497 Playfield Switch Cable x
H-16499 Playfield Solenoid Cable x
H-16500 Insert Cable x
H·16501 Cabinet Cable x
H-16599 Coin Door Cable . DBV x
(jJafPLt /MIDWAY 1-29
