Page 71 - BallyMidway GREY Parts Catalog 16-9562-A

SEO Version

r
Opto Assemblies and Locations - cont'd
Opto LED Assembly
A-1690B
Part Number
Description
A-14231
03-8506-1
4104-01001-06
LED Assembly
White Mounting Base
SMS #4 x 3/8 P-PH-A
Indy500
World Shadw Corvet
Addam
Magic Who?
Part Number
Description
50026 50031 50032 50036 50038 50039 50044
Game and Part Quantity
A-15199
Opto Ball Guide Assembly
1
A-17633
Coin Toss Assembly
3
A-17741
Goalie Unit Assembly
2
A-17742
Trough Assembly
1
A-17839
Goalie Ball Popper Assembly
1
A-17854
Small Ramp Assembly
1
A-17855
Large Ramp Assembly
1
A-18213
Right Ball Popper Assembly
1
A-18388
Magnet Opto Assembly
1
A-18518
Opto Bracket Assembly
1
A-19005
Popper Assembly
1
A-19007
Loop Assembl}'_
1
A-19008
Engine Ramp Assembly
1
A-19009
Race Track Ramp Assembly
1
A-19170
MotorlOpto Assembly
1
A-19543
Ball Popper Assembly
1
A-19791
Front Trough Assembly
1
A-20159
8all Popper Assembly
1
A-20235
Ball Popper Assembly
1
A-20419
Underside Trough Assembly
1
A-20420
Main Ramp Assembly
2
A-20487
Bottom Trough Assembly
1
A-20488
Ball Popper Assembly
1
A-20491
Trough Assembly
1
