Part Number
Description
Opto Assemblies and locations - cont'd
Opto Photo Transistor Assembly
A-16909
A-14232
5671-12732-00
5768-13154-02
03-8506
4104-01001-06
Photo Transistor Assembly
Transistor NPN Photo
PCB Single Opto (Blue Mask)
Black Mounting Base
SMS
#4
x
3/8 P-PH-A
Crea Judge TwiZ Pop
Part No.
Description
20018 20020 50020 50022
Game and Part Quantity
A-15769
Right Ball Popper Assembly
1
A-15769-1
Upper Right Ball Popper Ass'y
1
A-15842
lower Right Ball Popper Ass'y
1
A-16058
Wire Chute Assembly
1
A-16062
Steel Center Ramp Assembly
1
A-16170
Steel lockup Trough Ass'y
2
A-16312
Gumbal! Popper Assembly
1
A-16326
Ball Guide, Mini Playfield
1
A-16518
Ball Guide, Mini Playfield
1
A-16536
Opto/Plate Assembly
1
A-16580
Left Ball Popper Assembly
1
A-16794
Right Ball Guide Assembly
2
A-17132
Bottom Wire Ramp
1
A-17170
Left Plastic Ramp Assembly
2
A-17177
Center Plastic Ramp Assembly
2
A-17laO
Left Ball Popper Assembly
1
A-1723l
Main Plastic Ramp Assembly
3
A-17247
Lifter Assembly
1
A-17258
Right Ball Popper Assembly
1
A-17402
Wheel Drop Guide Assembly
1
A-17403
Right Exit Ramp, Upper P[fd
1
A-17774
Kicker Coil Assembly
1
1-28
@am;/MIDWAY
