Unique Assemblies - cont'd
WHO?OUNNIT (50044)
Reel Assembly
A-20425
Item Part Number Desc ription
Item Part Nu mber
Desc ription
1 01-14075
Reels Mounting Frame
11 4004-01003-04 Mach. Screw, 4-40 x
1/4
n
(12)
2 01-14076
Motor Mounting Bracket (3)
12 4006-01003-04 Mach. Screw, 6-32 x 1/4" (6)
3 03-9410.1
Reel (3)
13 4006-01003-14 Mach. Screw, 6-32 x 7/8" (12)
4
14-8024
Stepper Motor, 1.8 (3)
14 4006-01076-04 Set Screw,. 6-32 x 1/4" (3)
5 A-20507
Socket & Bulb w/Diode (3)
15 4008-01003-04 Mach. Screw, 8·32 x
1/4" (14)
6 A-19745-1
Stepper Motor PCB w/Spacers (3)
16 4006-01003-03 Mach. Screw, 8·32 x 3/16" (3)
• 7 31-2517-3A Decal, Left
17 A-20511
Reel Opto PCB Assembly (3)
·S
31-2517-1A Decal, Center
18 03-7655-8
Wire Harness Clip,
1/2"
• 9 31-2517-2A Decal, Right
"19 H-20567
Cable
10 03-9454
Tie-Wrap· Nylon
3,7/8" (10)
20 03-7655-4
Wire Harness Clip, 1/4" (4)
• Nol available for individual sale. Order Decal Set 31-2517 .
•• Nol Shown.
