Page 519 - BallyMidway GREY Parts Catalog 16-9562-A

SEO Version

Unique Assemblies - confd
The ADDAMS FAMILY (50038)
-
Diverter Drive Assembly
A-15040
part Number
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
1L
12.
A-15041
20-8790
03-7066
01-8413
AE-26-1500
A·10821
4010-01008-06
4701-00004-00
10-437
A·13278
A-14,85
4010-01082-04
Description
Mounting Bracket
Nylined Bearing
Coil Tubing
Coi Mounting Bracket
Coil Assembly
Flipper Slop Bracket Assy.
Ma.ch. Screw, 10·32
II:
3/8
lockwasher
#10
Split
Spring Kicker
Plunger Assembly
Drive Arm Assembly
Set Screw, 10-32
II:
1/4-
SH-CP
Dlverter Assembly
Magnet Coil
&
Bracket Assemb ly
Item
1
2
Part Number
20-9247
A-15257
(jJafPLt
/MIDWAY
• Associated Part:
13.
A-1S039
Description
Coil Magnet
&
Thermal Breaker
Bracket & Pole Piece Assembly
5-99
