Page 518 - BallyMidway GREY Parts Catalog 16-9562-A

SEO Version

Unique Assemblies - cont'd
The ADDAMS FAMILY (50038)
,,
\\ '~A
,
,
,
,
,
,
\~.
Hand Drive Assembly
A-14711
Item part Number
Description
11m.
part Number
pescrlptlon
1.
A-15303
Bracket Assembly
11.
4700-00130-00 Flatwashwer, 1
X
2
X
16ga.
2.
14-7966
Motor 140
12.
4010-01062-10 Mach. Screw, 10·32 x
5/8"
3.
01-10561
Motor Bracket
13.
H-15228
Hand Cable Assembly
4.
31-1684
Hand- Decorated
14.
4008-01003-08 Mach. Screw, 8-32 x
1/2"
5.
02-4603
Magne! Core
15.
A·15285
Op!O Switch·2 PCB Assy.
6.
4006,01 003-04 Mach. Screw, 6·32 x
1/4"
16.
A-15310
Interrupler Assembly
7.
01-10655
Anti-Trap Bracket
17.
4010-01082-04 Set Screw, 10·32 x
1/4"
8.
31-1677
Washer, Color
18.
4010-01006-1 0 Mach. Screw, 10-32 x
518"
9.
A·12158·1
Coil Assembly
19.
03-7520
Ty·Wrap Nylon
10.
4020·01003-08 Mach.
Screw, 1/4·20
x
112"
5-98
