Unique Assemblies - cont'd
The SHADOW (50032)
FRONT VIEW
FRONT VIEW
W/O
SWITCH
SIDE VIEW
Extended Target Assembly
A-18622
Item Part Number
Description
Item Part Number
Description
1
03-9210
Extended Target
17 Not used
2 A-18776
Main Target Bracket Ass'y
18 03-7066-4
Tubing
3 01-13048
Coil Mounting Bracket
19 20-8712-25
"E" Ring 114(3)
4 SM-30-11
DO-DC
Coil Assembly
20 4010·01025-14 MS 10-32 x 7/8 P-RH
5 A-18745
Stop Bracket Assembly
21 4700-00079-00
FW
.250 x .500 x .0598 (2)
6 10-483
Compression Spring
22 10-497
Retractor Spring
7 A-19686
Target PLunger Ass'y
23 01-13646.1
Guide Actuator Plate
8 03-9209
Guide, Extruded
24 5647-12693-31 Mini Micro Switch
9 4008-01003-08 MS 8-32 x
112
P-PH-S
25 01-8240
Nut Plate
10 Not used
26 4002-01105-10 MS 2-56 x 5/8 P-PH-S
(2)
11 A-18746
Stop Bracket Assembly
27 01-8600
Switch Insulator
12 AL-23-aOO Coil Assembly
28 4408-01119-00 Nut #8-32 ESNA (10)
13 01-13050
Coil Mounting Bracket
29 H-19692
Target Cable Assembly
14 A-18752
Plunger/Bracket Ass'y
30 H-19739
Switch Cable Assembly
15 A-la778
Bushing Bracket ASs'y
31 5070-09054-00 Diode 1N4004. 1.0A
16 A-18777
Pivot Bracket Assembly
(jJam;
IM/DWAY
5-81
