Page 498 - BallyMidway GREY Parts Catalog 16-9562-A

Unique Assemblies - cont'd
The SHADOW (50032)
ITEM NUMBER 2 (PART NUMBER 21-67Q5 2) INTERNAl VIEW SHOWN.
Gun Assembly
A-18536
Item Part Number Description
1
2
3
4
5
6
7
8
9
10
11
12
13
Gun Handle, left
Gun Handle, Right
Gun Grip, Left
Gun Grip, Right
Trigger
Switch
Lockwasher, #10 lnt, Tooth
Mach. Screw, #10-32 x 3/8"
Cable Assembly
Extension Spring, Red
Fastener, Butt Head
Lockwasher, 1/4" lnt, Tooth
Flatwasher, 13/64 x 15/32 x 21ga.
21-6705-1
21-6705-2
03-9196-1
03-9196-2
01-12942
5647-12133-16
4702-00013-00
4010-01097-068
H-19739
10-320
02-5041-15G
4702-00014-008
4700-00129-008
5-80
(jJaI!&j /MIDWAY
