The ADDAMS FAMilY (50038)
Ramp Assemblies - cont'd
(Mounted under the Playfield)
A-15486
Chute Guard
12-7040
- - -+ - tI.
Chute Wire
A-15070
Mini-Micro Switch
w/507~09054-00 Diode
A-15200
Item Part Number
Description
1 A-15201
Kickout Sub-Assembly
2 03-7067
Coil Tubing
3 AE-23-800
Coil Assembly
4 01-9423
Coil Bracket - Inner
5 4408-01119-00 Nut 8-32 ESN (2)
6 10-135
Solenoid Spring
7 A-13270
Bell Armature Assembly
8 23-6420
Rubber Grommet
9
5647-12693-25 Mini Micro Swrtch
10 4002-01105-07 MS 2-56 x
7/16
P-PH-S (2)
11 5070-09054-00 Diode 1N4001, 1.0A
12 01-8240
Nut Plate #2-56
13 A-15376
Coil Bracket - Front
14 4008-01003-06 MS 8-32 x 3/8 P-PH-S (2)
15 01-8600
Insulator
