Page 276 - BallyMidway GREY Parts Catalog 16-9562-A

The ADDAMS FAMILY (50038)
Ramp Assemblies - cont'd
(Mounted under the Playfield)
A-14962
Item
1
2
3
4
5
6
Part Number
A-14963
5647-12693-25
5070-09054-00
01-8240
4002-01105-07
01-8600
Description
Loop Sub-Assembly
Mini Micro Switch
Diode 1N4001, 1.0A
Nut Plate #2-56
MS 2-56 x 7/16 P-PH-S (2)
Insulator
Note: See p. 5-28a for related Kicker Ass'y, A-15115.
A-14964
Item
1
2
3
4
5
6
Part Number
A-14965
5647-12693-25
5070-09054~00
01-8240
4002-01105-07
01-8600
Description
Lockup Loop Assembly
Mini Micro Switch
Diode 1N4001, 1.0A
Nut Plate #2-56
MS 2-56 x 7/16 P-PH-S (2)
Insulator
Note: See p. 5-28a for related Kicker Ass'y, A-14107.
3-42 (jJaI!&j /MIDWAY
