Pinball Cabinet Assemblies - cont'd
SAVES THE EARTH
(50022)
Item Part Number
Description
Item Part Number
Description
1 C-10843-2
Leg Assembly (4)
12 A-15361
Tilt Mechanism Assembly
2 A·16970-120V Une Filter Assembly
13 555~12929-00 Speaker 6',4.(1, 25W
2a 58S0-13271-00 Line Cordset
14 5610-13491-00 WPC Transformer 1151230V
3 8-12273-6
Flipper Button Ass'y (2)
15 (See Sect. 8) Cashbox Assembly
4
A-17316
Flipper Opto Assembly
A-17195
Tilt Switch & Cable Ass'y
5 Not used
6 (See Sect. 8) Coin Door Assembly
Unique Assemblies:
7 A·16773
Lever Guide Assembly
8
A-16055
Front Molding Assembly
16t 2Q-9663-9
"Extra Ball· Button
9
20-9663-1
'Start' Button
17t 20-9663-B-4 "Launch" Button
10 A-17316
Flipper Opto Assembly
11 A-14689
WPC Coin Door Interface Bd "Mounted on Cabinet floor.
tMounted on front of Cabinet.
