Drop Target Assemblies ~ confd
4-Bank Drop Target Assembly
18188
Item Part Number
Description
Item Part f!..!umber
Description
1 A-18186
Bracket
&
Stud Assembly
11 20-8712-18
"eO
Ring, 1/4" Shaft (8)
2 A-11397
Stop Bracket Assembly
12 4700·0007.2-00 FW .265 x .500 x .032 (a)
3 4406-01119-00 Nut 8·32 ESNA (4)
13 10-392
Extension Spring (4)
4 AE-24-900
Coil Assembly
14 10-362
Retractor Spring (4)
5 03-7066-4
Coil Tubing
15 23·6626
Rubber Grommet (4)
6 A-13453
Reset Plate Assembly
16 A·19103
4-Bank Opto PC Board
7 01·9548
Coin Mounting Bracket
17 4700-00016-00
FW
3116
x 7/16 x 21ga. (2)
8
4010-01025-14 MS 10-32 x 7/8 P-RH (2)
18 20-8712-18
"E' Ring,
3/16"
Shaft (4)
9 4004-01005-04 MS 4-40 x 1{2 P-PH (5)
19 03·8334-4
Target Stop
10 03-8749
Plain Target, Black (4)
5~24
CiJ'f~®
