Page 226 - Williams GREEN Parts Catalog 16-9932

Rollover Wire Switch and Bracket Assemblies - cont'd
STAR TREK (50023)
Used on Assembly
Part Number Description
Quantity
Per Game
5647-12693-19 *A-12688
a) 01-8719
b) 4002-011 05-06
c) 5070-09054-00
d) 5647-12693-19
RO SwitchlBrkl Ass'y
Mounting Bracket
MS 2-56 x 3/8 (2)
Diode 1N40Q4, 1.0A
Mini-Micro Switch
*A-12688-1
a) 01-8719-1
b) 4002-01105-06
c) 5070-09054-00
d) 5647-12693-19
RO Switch/Brkt Ass'y
Mounting Bracket
MS 2-56 x 3/8 (2)
Diode 1N40Q4, 1.0A
Mini-Micro Switch
4
*A-17791
a) 01-12356
b) 4002-01105-06
c) 5070-09054-00
d) 5647-12693-32
RO Switch Assembly
Mounting Bracket
MS 2-56 x 3/6 (2)
Diode 1N40Q4, 1.0A
Mini-Micro Switch
- - - -
Used on Assembly Quantity
ROAD SHOW (50024) Part Number Description Per Game
5647-12693-19 *A-17813 RO Switch Assembly 12
a) 01-12356 Mounting Bracket
(See STAR TREK above) b) 4002-01105-06 MS .2-56 x 3/6 (2)
c) 5070-09054-00 Diode 1N4004, 1.0A
d) 5647-12693-19 Mini-Micro Switch
5647-12693-.20 A-19046 Loop Assembly 1
(See p. 5-68)
A-19047 Front Trough Ass'y 1
(See p. 3-48)
A-19225 Pop Up/Switch Ass'y 2
(See p. 5-67)
A-19231 Rear Trough Ass'y 1
(See p. 3-49)
5647-12693-32
4-32
*See p, 4-37
