JOKERZ! (567)
Wireform and Ball Gate Locations
Item Part No.
Description
1 A-12209
Ball Gate Assembly
2
12-6466-8
Wireform, 2"
3
A-12160
Ball Gate Assembly
4
12-6466-6
Wireform, 1-1/2" (2 used)
5
A-9465-R
Ball Gate Assy. (2 used)
6
A-9465-L
Ball Gate Assy.
(2
used)
7
12-6806
Shooter Lane Wireform
8
A-8645
Rollover Wire & Brkt Assy.
9
A-5844-44
Rollover Wire & Brkt Assy.
10 A-5844-45
Rollover Wire & Brkt Assy.
11
12-6542
Ball Return Gate Wire
12
12-6468
Anti-Rebound Wire
4-12i
