Page 275 - Williams BLUE Parts Catalog 16-9064-B

SEO Version

Description
BLACK KNIGHT 2000 (563)
ELECTRONICS GAMES. INC.
Wireform and Ball Gate Locations
Wireform,
1-1/2"
Wireform, 3-314"
Wire Ramp
Wireform, 3"
Rollover Wire & Brkt Assy.
Rollover Wire
&
Brkt Assy.
Rollover Wire & Brkt Assy.
Ball Return Gate Wire
Anti-Rebound Wire
Bottom Arch Fence
Wire Ramp
3-Ball Lockup Wire Ramp
Curved Ball Guide Wireform
Popper Wire Ramp
Wireform,
314"
Ball Gate Assembly
Shooter
Exit
Wire Ramp
Ball Gate Assembly
Ball Gate Assembly
Lower Playfield
Item Part No.
1 12-6466-6
2 12-6466-15
3 12-6827
4 12-6466-12
5 A-8645
6 A-5844-44
7 A-5844-45
8 12-6542
9 12-6468
10 12-6842
Upper Playfield
11 12-6830
12 B-12693
13 12-6846
14 12-6826
15 A-6466-3A
16 A-12640
17 12-6831
18 B-12708
19 B-12720
