Page 270 - Williams BLUE Parts Catalog 16-9064-B

Item Part No. Description
1 12-6718 Left Wire Return Ramp
2 12-6466-5 Wireform, 1-1/4"
3 12-6468-3 Anti-Rebound Wire
4 12-6466-4 Wireform, 1"
5 12-6466-7 Wireform, 1-3/4"
6 12-6746 Gate Wire
7 12-6744 Ball Popper Wire Ramp
8 12-6756 Wi reform
9 A-11803 BaHGate Assembly
\)i)DLJG7
10 12-6466-6A Wi reform , 1-5/8"
n 12-6743 Shooter Lane Wire Ramp
12 A-11126 Ball Gate Assembly
13 12-6719 Right Wire Return Ramp
14 12-6466-2 Wireform, 1/2"
15 A-l0607 Post & Gate Wire Assy.
16 A-8645 Rollover Wire & Brkt Assy.
17 A-5844-44 Rollover Wire & Brkt Assy.
18 A-5844-45 Rollover Wire & Brkt Assy.
19 12-6542 Ball Return Gate Wire
20 12-6468-2 Anti-Rebound Wire
BIG GUNS (557)
Wireform and Ball Gate Locations
4-12d
